THINKCAR ThinkScan Max 2 Car Diagnostic Tools Full system Support CANFD IMMO 28 Resets OBD2 Scanner ECU Coding Bi-Directional

New THINKCAR THINKSCAN MAX 2, 5.99inch Android 10 All Systems Automotive Diagnostic Tool, support CANFD For GM, 28 Resets, All OBD Function Car OBD2 Scanner, Auto Vin Scan, Lifetime Free Update, FCA account log in (Pay extra), 2GB + 32GB, 3150mAh Battery

NOTE:

1. THINKSCAN MAX 2 software has been upgraded. No registration is required ！No registration is required ！No registration is required！

2. It cannot be bound to a THINKCAR account, you can use it after turning it on!

3. THINKSCAN MAX 2 cancel the mall function

4. THINKSCAN MAX 2 is equipped with the VCI connector of THINKDIAG MINI 2 European Version VS. Global Version * The European version has IP restrictions and is only available for European addresses.

What Is the Different Between EU Version And Global Version ?

1. The EU Version is designed for European customers and only supports working in the European region ( including Russia and UK).

2. The Global Version has no IP restrictions and can be used worldwide.

THINKSCAN MAX2 Covers Multiple Functions And It Is A Great Companion For Cars

1. 【Free Lifetime Software Upgrade】: No more worrying about spending high annual fees on upgrading software.

2. 【Add CANFD Protocols】: CAN-FD protocol supports the GM vehicles manufactured after 2021.

3. 【32GB More Storage】: Never worry about downloading software without storage space again.

4. 【Portable Bluetooth Connector】: Easy to hang, more convenient to plug and unplug, waterproof and shock-proof.

5. 【15 Languages Support】: Added to 15 kinds of languages, no language barrier and no geographical limitations.

6. 【28+ Reset Funstions】: Advanced 28+ car maintenance functions, it ensures that the vehicle is in a state of excellent performance and makes the owner feel more comfortable.

7. 【Remote Tech Support】: If you are newbie, pls don't worry, we have one-on-one remote assistance service, you just need to sit in front of the computer and watch us help you solve any problem.

8. 【Supports AutoAuth for FCA SGW】: Allowing you to unlock protected FCA vehicle SGW module for Chrysler, Dodge, Jeep, Alfa Romeo, and Fiat vehicles manufactured after 2019 and perform diagnostics, such as read/clear codes, data stream, etc. (* Only provide AutoAuth login portal, and need purchase the registration number on the AutoAuth website by yourself ).

9.[OE-Level AlI System Diagnostic]+[ ECU Coding]+[ Action Test ]+[Intelligent AutoVIN ]+[ Report Share] +[ 4 in 1 Datastream Graph]: Strong Function

10.[Powerful configuration]: Android 10.0 +2G RAM+ 32G Storage + 5.99 inches Screen Size.

Thinktool Max 2 Is Upgraded Version Of Thinktool Max

*More Storage Memory And Higher System Verion，And The Most Important Function，It Has CANFD Protocol
* THINKSCAN MAX 2 has 32G memory, which solves the problem of insufficient memory of THINKSCAN MAX 16G

THINKSCAN MAX 2 Lifetime Free Update

THINKSCAN MAX 2 Is Lifetime Free Update ! All System Diagnose Function , OBD2 Function and 28 Reset Function , All Are Lifetime Free Update ！It Will Help You To Save More Money

Thinkscan Max2 Added CAN-FD Protocol

This automotive diagnostic scanner is compatible with CAN-FD protocol and supports GM vehicles manufactured after 2020. Adopts advanced CRC algorithms to accommodate more data from 8 to 64 bytes in the CAN frame, which runs faster than other products and reduces the risk of undetected errors to greatly enhance the user experience.

Thinkscan Max2 Active Test ( This Function Need Subscription )

Active Test (Bi-direction Tests) can test whether the actuator is normal or not , like turn on the radiator fan, adjust the throttle, open/close windows etc .

Autoauth for FCA SGW (Need to pay extra)

Use the latest software update function AutoAuth to provide diagnosis, making the diagnostics more secure.

Applicable to FCA vehicles (for Chrysler, for Dodge, for Fiat, etc. after 2017) equipped with a security gateway module (SGW).

Thinkscan Max2 ECU Coding (This Function Need Subscription )

ECU coding can carry out the customer's personalized customization of the car, can do some hidden function, such as setting alarms, door locks and outdoor lighting, etc .

THINKCAR ThinkScan Max 2 Support 17+Language :

English, French, German, Italian, Spanish, Portuguese, Japanese, Russian, Polish, Hungarian, Arabic, Greek, Slovak, Korean, Swedish, Dutch, Traditional.

ThinkScan Max2 Supports 10000+ car models from the US, Europe, Asia and China

For Amercian
for B–uick, for C–hrysler, for C–illac, for C–vrolet, for D–ge, for AU F–rd, for B–azil Fiat, for Brazil G–M, for F–ord, for G-M, for J-eep, for L-incoln, for S-GM

For European
for A-ston Martin, for A-udi, for A-lfa Remeo, for A-barth, for B-MW, for B-entley, for B-ugatti, for C-itroen, for DR, for Dacia, for EU Fo-d, for Ferrari, for Fiat, for GAZ, for Iveco, for IZH, for Jaguar, for La-nd Rover, for Lamborghini, for Lancia, for Mercedes, for Maserati, for Maybach, for Opel, for Opel (south africa), for PAZ, for Peugeot, for Porche, for Renault, for Rover, for Rolls-royce, for SAAB, for Seat, for Skoda, for Smart, for Sprinter, for UAZ, for VAZ, for Volvo, for Volkswagen, for Vauxhall, for ZAZ

For Asian
Acura, for Daewoo, for Daihatsu, for AU Holden, for Honda, for Hyundai, for Ikco, for Isuzu, for Infiniti, for Kia, for Luxgen, for Lexus, for Mahindra (India), for Maruti (India), for Tata (India), for Mahindra, for Maruti, for Mazda, for Mitsubishi, for MVM, for Nissan, for Nissangtr, for Perodua (Malaysia), for Proton (Malaysia), for Perodua, for Proton, for Renault Samsung, for Saipa, for Ssangyong, for Subaru, for Suzuki, for Toyota, for Tlisuzu, for United Pakistan

For China Car :
For BAIC SENOVA , For BAIC WEIWANG, For BAIC , For BRILLIANCE , For BYD , For CHANGAN , For CHANGANFORD , For CHANGHE , For CHBUICK , For CHCADILLAC , For CHCHEVROLET , For CHERY , For CHSUZUKI , For DFCITROEN , For DFNISSAN , For DFPEUGEOT , For DFSK , For ECUAID , For FAW(TIANJIN) , For FOTON , For GONOW , For GWM , For HAFEI , For HAIMA , For HCBMW , For HONDA(GAC) , For JAC , For JINLONG , For JMC , For JOYLONG , For LIFAN , For LUXGEN , For LYNKCO , For MAXUS , For MG(SAIC) , For MITSUBISHI(GAC) , For NJFIAT , For POLARSUN , For QOROS , For SGMW , For TOYOTA(CHINA) , For XINKAI , For YQMAZDA , For ZOTYE , For ZX AUTO

28 Maintenance Reset Functions

It allows you to reset various systems in your vehicle. support more function than other scanners priced similarly.

1. Oil Reset ( Supports 53 Brands )
The lightening of the car maintenance light indicates that the vehicle needs maintenance.Reset themileage or driving time to zero after the maintenance, so the maintenance light will go out and the systemwill start a new maintenance cycle.

2. Elec.Throttle Adaption ( Supports 37 Brands )
Elec. Throttle Adaption is to utilize the car decoder to initialize the throttle actuator so that the learningvalue of the ECU returns to the initial state.By doing these, the movement of the throttle (or idle motor)can be more accurately controlled, thus adjust the intake volume.

3. SAS – Steering Angle Reset ( Supports 44 Brands )
To reset the steering angle, first find the relative zero point position for the car to drive in straight line.Taking this position as reference, the ECU can calculate the accurate angle for left and right steering.After replacing the steering angle position sensor, replacing steering mechanical parts (such as steeringgearbox, steering column, end tie rod, steering knuckle), performing four-wheel alignment, or recoveringcar body, you must reset the steering angle.

4. Battery Matching ( Supports 33 Brands )
This function enables you to perform a resetting operation on the monitoring unit of vehicle battery, inwhich the original low battery fault information will be cleared and battery matching will be done.

5. ABS Bleeding ( Supports 34 Brands )
When the ABS contains air, the ABS bleeding function must be performed to bleed the brake system torestore ABS brake sensitivity. lf the ABS computer,ABS pump, brake master cylinder, brake cylinder, brakeline, or brake fluid is replaced, the ABS bleeding function must be performed to bleed the ABS.

6. Brake Reset ( Supports 41 Brands )
lf the brake pad wears the brake pad sense line, the brake pad sense line sends a signal sense line to theon-board computer to replace the brake pad.After replacing the brake pad, you must reset the brake pad.Otherwise, the car alarms.

7. DPF Regeneration ( Supports 39 Brands )
DPF regeneration is used to clear PM (Particulate Matter) from the DPF filter through continuouscombustion oxidation mode (such as high temperature heating combustion, fuel additive or catalyst reducePM ignition combustion) to stabilize the filter performance.

8 Gear Learning ( Supports 22 Brands )
The crankshaft position sensor learns crankshaft gear machining tolerance and saves to the computerto more accurately diagnose engine misfires. lf gear learning is not performed for a car equipped withDelphi engine, the MlL turns on after the engine is started.The diagnostic device detects the DTC P1336'gear not learned'. In this case, you must use the diagnostic device to perform gear learning for the car.After gear learning is successful, the MIL turns off. After the engine ECU, crankshaft position sensor, orcrankshaft flywheel is replaced, or the DTC 'gear not learned” is present, gear learning must be performed.

9. IMMO Service ( Supports 46 Brands )
To prevent the car being used by unauthorized keys, the anti-theft key matching function must beperformed so that the immobilizer control system on the car identifies and authorizes remote control keysto normally use the car. When the ignition switch key, ignition switch, combined instrument panel,ECu,BCM, or remote control battery is replaced, anti-theft key matching must be performed.

10. Injector Coding ( Supports 47 Brands )
Write injector actual code or rewrite code in the ECU to the injector code of the corresponding cylinder soas to more accurately control or correct cylinder injection quantity. After the ECU or injector is replaced,injector code of each cylinder must be confirmed or re-coded so that the cylinder can better identifyinjectors to accurately control fuel injection.

11. TPMS Reset ( Supports 39 Brands )
After the tire pressure MIL turns on and maintenance is performed, the tire pressure resetting functionmust be performed to reset tire pressure and turn off the tire pressure MIL.Tire pressure resetting mustbe performed after maintenance is performed in the following cases: tire pressure is too low, tire leaks, tirepressure monitoring device is replaced or installed, tire is replaced, tire pressure sensor is damaged,andtire is replaced for the car with tire pressure monitoring function.

12. Suspension Matching ( Supports 14 Brands )
This function can adjust the height of the body. When replacing the body height sensor in the airsuspension system, or control module or when the vehicle level is incorrect, you need to perform thisfunction to adjust the body height sensor for level calibration.

13. AFS Reset ( Supports 21 Brands )
This feature is used to initialize the adaptive headlamp system.According to the ambient light intensity, theadaptive headlamp system may decide whether to automatically turn on the headlamps, and timely adjustthe headlamp lighting angle while monitoring the vehicle speed and body posture.

14. A/T Learning ( Supports 14 Brands )
This function can complete the gearbox self-learning to improve gear shifting quality. When the gearbox isdisassembled or repaired (after some of the car battery is powered off), it will lead to shift delay or impactproblem. In this case, this function needs to be done so that the gearbox can automatically compensate according to the driving conditions so as to achieve more comfortable and better shift quality.

15. Sunroof Initialization ( Supports 4 Brands )
This function can set the sunroof lock off, closed when it rains,sliding / tilting sunroof memory function,temperature threshold outside the car etc.

16. EGR Adaption ( Supports 10 Brands )
This function is used to learn the EGR (Exhaust Gas Recirculation) valve after it is cleaned or replaced.

17. ODO Reset ( Supports 10 Brands )
a) ODo reset is to copy,write, or rewrite the value of kilometers in the chip of odometer by using a cardiagnostic computer and data cable, so that the odometer shows the actual mileage.
b)Usually when the mileage is not correct due to the damaged vehicle speed sensor or odometer failure, it is necessary to do ODo reset after maintenance.

18. Airbag Reset ( Supports 12 Brands )
This function resets the airbag data to clear the airbag collision fault indicator. When the vehicle collidesand the airbag deploys, the corresponding fault code of the collision data appears, the airbag indicatorlights up, and the fault code cannot be cleared. Since the data inside the airbag computer is disposable,it is required that all new accessories must be replaced, but after performing this function, the data of theairbag computer can be recovered and the fault code can be cleared, the airbag light will go out, and theairbag computer can continue to use.

19. Transport Mode ( Supports 13 Brands )
ln order to reduce power consumption, the following functions may be disabled,including limiting thevehicle speed, not waking up the door opening network, and disabling the remote control key, etc. At thistime, the transport mode needs to be deactivated to restore the vehicle to normal.

20. A/F Reset ( Supports 5 Brands )
This function is applied to set or learn Air/Fuel ratio parameters.

21. Stop/Start Reset ( Supports 5 Brands )
This function is used to open or close the automatic start-stop function via setting the hidden function inECU(provided that the vehicle has a hidden function and supported by hardware).

22. NOx Sensor Reset ( Supports 12 Brands )
NOx sensor is a sensor used to detect the content of nitrogen oxides (NOx) in engine exhaust. lf theNOx fault is re-initialized and the NOx catalytic converter is replaced, it is necessary to reset the catalyticconverter learned value stored in the engine ECu.

23. AdBlue Reset (Diesel Engine Exhaust Gas Filter – Supports 8 Brands)
After the diesel exhaust treatment fluid (car urea) is replaced or flled up, urea reset operation is required.

24. Seat Calibration ( Supports 26 Brands )
This function is applied to match the seats with memory function that are replaced and repaired.

25. Coolant Bleeding ( Supports 5 Brands )
Use this function to activate the electronic water pump before venting the cooling system.

26. Tyre Reset ( Support 13 Brands )
This function is used to set the size parameters of the modified or replaced tire.

27. Windows Calibration ( Supports 24 Brands )
This feature is designed to perform door window matching to recover ECU initial memory, and recover theautomatic ascending and descending function of power window.

28. Language Change ( Supports 22 Brands )
This function is used to change the system language of the vehicle central control panel.

Full OBD2 Function (Lifetime Free update )

Reading Codes: Show the detailed description of the Diagnostic Trouble Code (DTCs)

Erasing Codes & Reset: Turns off Check Engine Light (MIL), clears codes and resets monitors.

Data Stream: Reads and displays live ECU/PCM data stream, plotting functions graphically and stores freeze frame data.

I/M Readiness Status: Shows whether the various emissions-related systems on the vehicle are operating properly and are ready for inspection and maintenance testing.

Read Live Data Stream: Show the information of continuous data stream from a vehicle in live graphic (waveform) display.

View Freeze Frame Data: Check the certain vehicle conditions which are recorded by the on-board computer at the time the emission-related fault occurs.

O2 Sensor Test: Allows retrieval and viewing of O2 sensor monitor test results for the most recently performed tests from the vehicle’s on-board computer.

On-Board Monitor Test: Retrieves and displays test results for emission-related powertrain components and systems.

Read Vehicle Information: Display the information such as VIN (Vehicle Identification Number), CID (Calibration ID) and CVN (Calibration verification number), etc.

Component Test: Certain vehicle components can be actuated by commands sent from the scanner to test their operability.

ThinkCar ThinkScan Max 2 have full system Diagnose Function

For Engine: detect common issues as Poor lubrication, Failing oil pump, Oil deposits and debris, Inadequate fuel and air compression, Leaking engine coolant, Blocked engine radiators, Prolonged engine detonation, Damaged oxygen sensors, Aged spark plugs, etc.
For SRS: pinpoint the trouble area as: a bad seat belt, a corroded crash sensor, or some water intrusion in a connector, etc.
For ABS: diagnose Blown sensor fuse, Low brake fluids, and Faulty sensor, etc.
For Transmission: avoid Grinding or shaking sensation in gear, Whining, humming or clunking noises, Burning smells, Gears Slipping, Low or Leaking Transmission Fluid, etc.
For TPMS: verify problems of Low tire pressure, Faulty in tire pressure monitor control module, Unknown tire sensor, Failure to identify tire sensor, etc.

Auto-VIN & Wireless Connection

Car diagnostic scanner for all cars quickly establishes a connection with the car through the built-in WiFi and Bluetooth which makes it more convenient to diagnose your vehicle.

Screenshot & Screen Recorder

You can capture and save the diagnositc process with this feature rather then use the telephone to take pictures.

Subscription Price

ECU Coding & Action Test need subscription , $49.95/year

What is More？

1.AUTO VIN SCAN :
Click “diagnose” and “autosearch” after connecting to the vehicle. Then the thinktool automotive diagnosti tool will begin to scan the VIN automatically.

2.4 Data display in 1 Graph:
It will Read vehicle’s live data, and present by graph. Optional combination of multiple data.
Live Data Stream combined Graphing+Data Record better for monitoring vehicle performance and analyze the abnormal parameter.

3.Diagnosis Function Record Playback:
Record your problem in detail and understand the problem more effectively.

4.Print the vehicles report:
Full system Vehicle health report will be automatically created after diagnosis, report can be shared.

5.One-Key Screenshot and share via email:
Use the feature to capture and save the diagnostic process for you rather than take pictures by telephone.you can share with your friend.

6.Battey Voltage monitor:
One-key voltage monitoring, More safer.

How to Register ThinkCar ThinkScan Max 2 ?

Step 1 : Choose Time Zone
Step 2 : Agree the agreement term
Step 3 : New Registration , Create APP Account .

Packing List of THINKSCAN MAX 2:

1PC * THINKSCAN MAX 2 Host
1PC * EVG Storage Bag
1PC * VCI Dongle
1PC * Charging cable
1PC * Power adapter
1Pc * User Manual (multi-language）
