Autel MaxiCOM MK906PRO Car Diagnostic Scan Tools Automotive OBD2 Scanner ECU Coding CAN FD DoIP PK MK906BT MS906PRO

Autel MaxiCOM MK906PRO Car Diagnostic Scan Tools Automotive OBD2 Scanner ECU Coding CAN FD DoIP PK MK906BT MS906PRO

MaxiCOM MK906PRO is the latest addition to the MaxiCOM product line of advanced wireless diagnostic devices. The device is based on the Android operating system featured with the best possible coverage of OE-level diagnostics and ECU coding capability. Utilizing the powerful Exynos 5260 6-core processor (1.3 GHz quad-core ARM Cortex-A7 + 1.7 GHz dual-core ARM Cortex-A15), an 8” capacitive HD touch screen, and long-distance wireless communication, the MaxiCOM MK906BPRO efficiently provides comprehensive vehicle diagnostics and analysis.

Full-System Diagnostic

By penetrating all available ECUs, including but not limited to PCM, ECM, EPS, PDM, TPM, BCM, ABS, SCCM, etc., MK906Pro retrieves information and performs OE-level diagnostics on all available vehicle systems, like read and clear codes, view data stream and vehicle information, ECU Replacement, Zero Point Calibration (Toyota), Signal Check (Toyota), Initialization (ECU), and Guided Function (VAG). It not only enables you to troubleshoot promptly but also makes you customize the configuration.

Full-System Diagnostic

By penetrating all available ECUs, including but not limited to PCM, ECM, EPS, PDM, TPM, BCM, ABS, SCCM, etc., MK906Pro retrieves information and performs OE-level diagnostics on all available vehicle systems, like read and clear codes, view data stream and vehicle information, ECU Replacement, Zero Point Calibration (Toyota), Signal Check (Toyota), Initialization (ECU), and Guided Function (VAG). It not only enables you to troubleshoot promptly but also makes you customize the configuration.

ECU Coding

Same as Autel Maxisys MS906BT/MS908/MK908, Maxicom MK906BPRO has the capability of ECU coding to change preprogrammed options in the software, helping you customize your car faster as needed.

Optimally code your car by changing some settings to fit your needs, such as setting alarms, doors locking, etc.
1. Access the ECU to make full use of the hidden features or disable the car’s annoying functions, like activating the auto side mirrors folding function, disabling the automatic engine Start-Stop function, etc.
2. Provide excellent solutions for issues of drivability, power loss, fuel efficiency, etc. to improve the car’s performance.
3. Reprogram the adaptive data for certain components after repairs or replacements.
ECU Online Coding is available for BMW, VW, Porsche, Renault, etc.
Please Note: ECU Coding changes preprogrammed options which depend on the type and number of electronic features already built in. Thus, ECU coding is not universally compatible and varies for different vehicles.

Active Test

By passing the electronic control module and communicating directly with the control unit is an efficient diagnosis method. The MK906BT car scanner can perform active tests to check the vehicle’s running states by receiving information from ECUs or by monitoring actuators (e.g., switching solenoids, relays, or on-off between two operations) to control the system or parts (e.g., ABS, windows, doors, roof).

36+ Maintenance Functions

As the latest version of 2021, the diagnostic tool is competent to perform Oil Reset, Injector Coding, Throttle Matching, ABS Bleeding, BMS Service, SAS Reset, IMMO, Key Fob Coding, and more. MK906BT diagnostic scanner is an all-around maintenance scanner for effectiveness and efficiency.

Oil Reset Service

to reset service mileage and service intervals for the Engine Oil Life system;

TPMS Service

to look up the tire sensor IDs from ECU, as well as to perform TPMS programming and reset procedures after sensor replacements;
*Note: The TPMS function cannot program sensors.

EPB Service

to deactivate and activate the brake control system, assist with brake fluid control, open and close brake pads, and set brakes after disc or pad replacement, etc.;

ABS/SRS Services

to perform bi-directional tests to check the operating conditions of ABS and SRS, such as Automated Bleeding, Pump Motor Test, and checking Module information, etc.;

SAS Service

to perform calibration for the Steering Angle Sensor, and clear fault memory;

DPF Regeneration Service

to clear the blockage through the continuous burning of the particulate matter captured in the DPF filter

BMS Service

performs a reset on the vehicle battery for clearing the fault information and re-match the battery;

Brake Bleed

performs various bi-directional tests to check the operating conditions of Anti-lock Braking System (ABS), and turn off the warning light;

IMMO Service

clear the lost car key’s information and program the new key into the ECU database to protect user’s car from being stolen;

Injector Coding

writes the new code to the ECU after replacement of injector, so that the injector works;

Throttle Adaptation

initialize the throttle actuators to the default state for regulating throttle (or idle engine) operations accurately;

Headlamp / Suspension / CHG tire size / TEC learn / WIN DR ROOF /Seats / Lang change

and many more……

Auto VIN

Just one click can facilitate the vehicle diagnostic process. MK906PRO scanner tool incorporates the latest Auto VIN technology that allows technicians or repairmen to easily identify vehicle information such as manufacturer, model, year and place of manufacture, etc.

Key Fob Programming

With IMMO Keys function, automotive diagnostic scanner MK906PRO can disable or clear info of the lost vehicle keys, add new keys, program the replacement key fob for most Asian and American vehicles. Note: Not available for BMW, Benz, Audi, etc.

Language

English, Simplified Chinese, Traditional Chinese, Spanish, French, German, Polish, Italian, Japanese, Korean, Dutch, Portuguese, Swedish, Russian

After you get the product, please tell us your SN of machine to activate the language you need .

Compatible with almost all vehicles

Autel OBD2 scanner MK906PRO can help almost all vehicles replace ECUs/modules, such as Honda, Jeep, Chrysler, VAG, GM, Peugeot, Citroen, Mitsubishi, Suzuki, etc. However, it’s NOT available for modules on the vehicles that need to do programming, online coding, online parameterization, and online matching.

Wide Coverage & Easy to Use

No need to worry about compatibility issues. The device currently supports 80+ car manufacturers and 140+ car brands worldwide. Also, you will be able to get more new car models through subsequent high-frequency software updates.

It is compatible with: Chrysler, Dodge, Ford, GM, Jeep, Abarth, Alfa, Citroen, Fiat, Lancia, Opel, Peugeot, Porsche, Renault, Saab, Vauxhall, Volvo, Aston Martin, Audi, Bentley, Benz, Sprinter, BMW, Bugatti, Ferrari, Jaguar, Lamborghini, Land Rover, Maserati, Maybach, Mini, Rolls-Royce, Seat, Skoda, Smart, VW, VW CV, Dacia, Ford EU, LT3, Acura, Daewoo, Daihatsu, Honda, Hyundai, Hyundai CV, Infiniti, Kia, Lexus, Maruti Suzuki, Mazda, Mitsubishi, Nissan, Nissan GTR, Samsung, Scion, Ssang Yong, Subaru, Suzuki, Toyota, Isuzu, Mahindra, Perodua, Proton, TATA, HINO, UD, Fuso.

Update Service & Warranty

1 year free upate service

1 year warrantry for any quality problem

Specifications

Operating System

Android™ 10

Processor

Octa-core processor (2.2 GHz Qual highperformance Kryo cores + 1.8 GHz Qual lowpower Kryo cores)

Memory

4 GB RAM & 128 GB ROM

Display

8.0-inch TFT-LED capacitive touch screen with 1920 x 1200 P resolution

Connectivity

Wi-Fi (802.11 b/g/n)

USB: 2.0, Mini USB 2.0

Wireless BT V2.1+EDR Class1, HDMI

SD Card (support up to 32 GB)

Camera (rear)

Rear: 16 megapixel, autofocus with flashlight

Front: 16 megapixel

Sensors

Gravity Accelerometer

Ambient Light Sensor (ALS)

Audio Input/Output

Input: microphone

Output: single speakers, 3-band 3.5 mm stereo/standard headset jack

Power and Battery

11,600 mAh 3.7 V lithium-polymer battery

Charging via 12 V AC/DC power supply

Input Voltage

12 V (9-35 V)

Power Consumption

5 W

Dimensions (W x H x D)

260 mm (10.0”) x 170.0 mm (6.9”) x 30.0 mm (1.4”)

Weight

NW: 0.92 kg (2.03lb.)
