17.3 inch（1600*900）18.5 inch（1366*768）19 inch(1280*1024) 21.5 inch（1920*1080） industrial PC resistive touch computer
industrial computer parameters
Brand：Balahome
Aterial：Metal
Memory: 4GB DDR3 System Memory (2GB/8GB/16GB optional)
Storage:64G SSD(128Gb/256Gb/512Gb/1TB optional)
System: WIN7/WIN8/WIN10/Liunx optional(Win7 Home Edition is installed by default)
BIOS: AMI BIOS
Graphic: IntelHD Graphics
Color: black (customizable color)
Weight: about 6-7Kgs
System Parameter：
Configuration 1：integrated Intel Celeron Processor J1900（4 cores, 2m cache, up to 2.00 ≤ 2.41 GHz,TDP power consumption:10w）
Storage space：64G SSD（ 128G / 256G Optional）
internal storage：4GB DDR3 System memory（8GB Optional）
Configuration 2：integrated Intel Core i3-4120U (dual core, 3MB cache, main frequency: 2.0 GHz, TDP power consumption: 15w)
Storage space：64G SSD（ 128G / 256G Optional）
Internal storage：4GB DDR3 System memory（8GB/16GB Optional）
Configuration 3：integrated Intel Core i3-6100U（Dual-core, 3MB cache, 2.3 GHz，TDP power consumption:15w）
Storage space：64G SSD（ 128G / 256G Optional）
Internal storage：4GB DDR3 System memory（8GB/16GB Optional）
Configuration 4：integrated Intel Core i5-4300U（Quad core, 3MB cache, 1.9 GHz，TDP power consumption:15w）
Storage space：64G SSD（ 128G / 256G Optional）
Internal storage：4GB DDR3 System memory（8GB/16GB Optional）
Configuration 5：integrated Intel Core i5-6360U（Quad core, 3MB cache, up to 2.00-3.10 GHz，TDP power consumption:15w）
Storage space：64G SSD（ 128G / 256G Optional）
Internal storage：4GB DDR3 System memory（8GB/16GB Optional）
Configuration 6：integrated Intel Core i7-3537U（Dual core, 4MB cache, 2.00 GHz，TDP power consumption:17w）
Storage space：64G SSD（ 128G / 256G Optional）
Internal storage：4GB DDR3 System memory（8GB/16GB Optional）
Configuration 7：integrated Intel Core i7-4500U（Quad core, 3MB cache, 1.9 GHz，TDP power consumption:15w）
Storage space：64G SSD（ 128G / 256G Optional）
Internal storage：4GB DDR3 System memory（8GB/16GB Optional）
Configuratio 8：integrated Intel Core i7-6500U（Quad core, 8MB cache, up to 2.50-3.10 GHz，TDP power consumption:15w）
Storage space：64G SSD（ 128G / 256G Optional）
Internal storage：4GB DDR3 System memory（8GB/16GB Optional）
Parameters of LCD Touch screen：
Brightness：250cd/m2
Contrast Ratio：1000:1
Viewing Angle：Horizontal(left/right): 150°(75°/75°)
Vertical(up/down): 150°(75°/75°)
Response Time：30 (Typ.)(Tr+Td) (ms)
Frame Rate：60Hz
Color system：PAL/ NTSC
Interface：1 x VGA + 1 x HDMI + 2 * COM (default 232 protocol interface) +1 x RJ45 + 4 * USB + 1 x audio
power requirement of system：+ 12V DC power input
Power adapter：input：100〜250VAC，50 / 60Hz
output：60W Adapter（12V 5A）
Working temperature：-20°C〜60°C
Relative humidity：0％〜90％relative humidity, no condensatio
Plug：AU,EU,USA,UK plug available
Menu Languages：English,,Francais,Italiano,Deutsch,Espanol,Russian,Traditional Chinese, Simplified Chinese,etc
VISA Hole distance：75*75mm
Delivery Time
Sample:1~5 working days.
10~100pcs:2~7 working days.
More than 100pcs :5~15 working days
Other parameters：
BIOS：AMI BIOS
Graphics Cards：integrated Graphics Cards
WiFi：built-in wireless WiFi
System：WIN7 / WIN8 / WIN10 / Linux(Win10 Pro is installed by default)
power requirement of system：+ 12V DC power input
Power adapter：input：100〜250VAC，50 / 60Hz
output：60W Adapter（12V 5A）
Working temperature：-20°C〜60°C
Relative humidity：0％〜90％relative humidity, no condensatio
★★★ SPECIAL REMINDER ★★★
LOGO/Product Model/Case Material/Add Touch Function/Add Built-in Speaker/Add Remote Control Function/Base Style/Screen Size/Interface Type/Power Type/Installation Mode(Wall-hang/Embedded/Open-frame),etc.,can be customized for you(But need to meet the requirements of MOQ).If you have this demand,please contact us,we will provide you with timely and thoughtful service!
Detailed size
Resolution: 17.3 inch(1600*900)18.5 inch（1366*768）19 inch(1280*1024) 21.5 inch（1920*1080）ppi
Unit of measure: mm
Sensitive Touch Rapid Response
resistive touch (single point touch, pressure sensing, touch strength: 45g~250g)
Product interface (support customization)
1 x VGA + 1 x HDMI + 2 * COM (default 232 protocol interface, please contact us to customize 485 protocol interface) +1 x RJ45 + 4 * USB + 1 x audio
Remarks: Support customized interfaces: such as DC24V power interface, aviation power interface, 6 Com interfaces, dual LAN network ports, etc. Please contact us for details, thank you.
The machine runs stably
24/7 stable operation
Efficient work for a long time, fast cooling
Metal case, resistant to high and low temperature environment
Industrial cold-rolled sheet metal shell, cold and high temperature resistance, as low as -20 ℃ ~ 60 ℃.
Can effectively adapt to stable work in harsh environments
About customization
Please contact customer service to state your needs.
Support logo, shell, color, function, interface and other customization, please contact us for the best price
Installation method, installation is easy and simple
1. Embedded installation
① Before installation, the cabinet needs to be opened, and the opening size should be slightly larger than the opening size specified by the product.
②Place the product into the recessed installation hole reserved on the installation panel.
③There are two square holes on both sides of the device. When installing, use one end of the clip to fasten the square hole, and the screw head on the clip is against the cabinet.
Then tighten the screws, the other three prescription holes are installed in the same way, and the embedded installation can be completed.
2. Wall-mounted installation
①Fix the wall mount bracket A on the wall with expansion screws.
②The wall bracket B is installed on the back of the all-in-one machine with screws.
③ Insert the bracket on the back of the all-in-one machine into the wall bracket to complete the installation.
Product application field display
Products are widely used in industrial control CNC industry, medical industry, factory production workshop,
Bank automatic ticket vending machines, supermarket advertising, video surveillance, etc.
packaging & shipping
1). Usually,we ship within 3-5 working days after payment receive,Items purchased after 12:00pm on Friday, on holiday,or over the weekend will be shipped within the next business day.
2). We many shipping options as possible,including DHL,UPS,EMS,Fedex and
TNT,ect.
Frequently Asked Questions
Q: Is the machine waterproof?
A: No, please contact customer service for machines that need waterproofing
Q: What is the standard installation method?
A: Embedded, wall-mounted
Q: Does it support desktop installation?
A: Yes, but you need to buy a desktop stand
Q: Why do I need to activate after reinstalling the system or upgrading?
A: Our default system is a cracked version, and does not support upgrading or reinstalling the system. If you need a genuine system, please contact us to buy it or buy it yourself.
